Cutler Hammer HMCPS003A0C Circuit Breaker | Series C HMCPS 600V 3A

Product Description:
The Cutler Hammer HMCPS003A0C is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 600V, 3A rating and a 65kA@480V AIC rating. This breaker uses a bolt-on connection and offers magnetic-only protection. It is CSA Certified, IEC Rated, and UL Listed for safety compliance.

Key Features:
✔ Part Number: HMCPS003A0C
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: HMCPS
✔ Voltage: 600V
✔ Amperage: 3A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: Bolt-On
✔ Protection: Magnetic Only
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/J
✔ Wire Size: 14 AWG (Min), 1/0 AWG (Max)
✔ Breaker Type: Standard
✔ Phase Connection: ABC
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679804247
