Product Description:
The Square D HOM2200 is a Molded Case Circuit Breaker from the HOMELINE family. It is a 2-pole, 120/240V, 200A breaker with a 10kA@240V AIC rating. This Plug-In breaker features Thermal Magnetic protection and is UL Listed, CSA Certified, and HACR compliant. It is compatible with Homeline Load Centers and supports wire sizes from 8 AWG to 2 AWG.
Key Features:
✔ Part Number: HOM2200
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: HOMELINE
✔ Type: HOM
✔ Voltage: 120/240V
✔ Amperage: 200A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 100A/HOM
✔ MCM Size: Min. 8 AWG, Max. 2 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Certification: CSA Certified, HAC
