Product Description:
The Square D JRA36200 is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 200A rating and a 200kA@480V AIC rating. This breaker uses an I-Line Style Plug-In connection and includes Thermal Magnetic protection. It supports wire sizes from 3/0 AWG to 350 kcmil for both copper and aluminum terminals.
Key Features:
✔ Part Number: JRA36200
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: JLA
✔ Voltage: 600V
✔ Amperage: 200A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 200kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: R
✔ Wire Size: 3/0 AWG to 350 kcmil (Cu/Al)
✔ Temp Rating: 28-158°F (-2-70°C)
✔ Certification: UL, CSA, NEMA, NOM, CE
✔ UPC: 785901272311
✔ GTIN: 00785901272311
✔ Country of Origin: Mexico
✔ Dimensions: 4.09 in x 7.52 in
✔ Weight: 6.85 lbs
