Siemens JXD22B225 Molded Case Circuit Breaker | 240V 225A 2P 65kA@240V Bolt-On Sentron Series
Siemens JXD22B225 Molded Case Circuit Breaker | 240V 225A 2P 65kA@240V Bolt-On Sentron Series
Price:
Sale
Sold out
Regular price
$1,193.92 USD
Regular price
$5,098.00 USD
Sale price
$1,193.92 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Low stock: 6 left
Couldn't load pickup availability
Product Description:
The Siemens JXD22B225 is a Molded Case Circuit Breaker from the Sentron Series family. It is a 2-pole, 225 amp breaker rated for 240 volts with a 65kA AIC rating and features thermal magnetic protection. This bolt-on connection breaker is designed for use in specific panelboards and switchboards. It does not include lugs, which must be sourced separately based on wiring specifications.
Key Features:
✔ Part Number: JXD22B225
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: JXD
✔ Voltage: 240
✔ Amperage: 225
✔ Poles: 2
✔ AIC rating: 65kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Frame Size: 400A/JD
✔ MCM Size: 500 MCM
✔ Breaker Type: Standard
✔ Terminal Connection: Lug
✔ Functions: LI - Long-Time and Instantaneous
✔ Phase: 1
✔ Panel Type: SB Switchboards Without Lugs, Sentron Panelboards
✔ Certification: HACR Rated, UL Listed
✔ Standards: HACR Rated, UL Listed
✔ UPC: 783643212879
✔ GTIN: 00783643212879
✔ Country of Origin: United States
✔ Dimensions: 7.5 in x 11 in
✔ Weight: 20
