Square D LA26300AC Circuit Breaker | 600V 300A 2P 30kA@480V I-Line

Product Description:
The Square D LA26300AC is a Molded Case Circuit Breaker from the I-Line family. It features 2 poles, 600V voltage, and a 300A amperage rating with a 30kA@480V AIC rating. This breaker uses a Plug In Panelboard connection and offers Thermal Magnetic protection.

Key Features:
✔ Part Number: LA26300AC
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: I-Line
✔ Type: LA
✔ Voltage: 600
✔ Amperage: 300
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 30kA@480V
✔ Connection: Plug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 400A/LA
✔ MCM Size: Min. Wire Size 1 AWG (Al) Max. Wire Size 250 MCM (Al), 600 MCM (Cu)
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: AC
✔ UPC: 785901009771
✔ GTIN: 00785901009771
✔ Country of Origin: Mexico
✔ Dimensions: 6 in x 11 in
✔ Weight: 7.38
✔ Panel Type: I Line Panelboards
✔ Standards: CSA Certified, UL Listed
✔ Certification: CSA Certified, UL Listed
