LCC6 Crouse-Hinds 2 in Cable Tray Conduit Clamp for Outside Rail Tray, Cast Iron

LCC6 Crouse-Hinds 2 in Cable Tray Conduit Clamp for Outside Rail Tray, Cast Iron

Running 2 in conduit off the side of an outside rail cable tray? The Crouse-Hinds LCC6 clamps that conduit straight to the rail and bonds it to the tray, so you get mechanical support and grounding continuity at the exit point without drilling or welding a thing.

The swivel hook swings clear of the pipe, so you set the LCC6 without taking it apart. It handles rigid steel, rigid aluminum, IMC, and EMT, and the knurled malleable iron body gives you a no-slip surface on both the conduit and the rail.

Common Applications

• Clamping 2 in conduit drops to the outside rail of a cable tray
• Grounding continuity between exit conduit and tray
• Power and control cable exits off tray runs

Key Features

• Swivel hook: Clears the conduit during install, no teardown needed.
• Knurled grip: No-slip surface on the conduit side and the tray side.
• Malleable iron body: Crouse-Hinds calls out malleable iron for strength.
• Zero drilling or welding: Mounts to the tray rail as-is.
• Bonds to tray: Rated to UL 467 for grounding and bonding.

Specifications

• Catalog Number: LCC6
• Conduit Size: 2 in
• Conduit Types: Rigid steel, rigid aluminum, IMC, EMT
• Tray Type: Outside rail cable tray
• Body Material: Cast iron
• Body Finish: Electrogalvanized with aluminum acrylic paint
• Hook and Fasteners: Steel, zinc electroplate finish
• Hook Cap: Vinyl
• Certification: UL 467
• Standards Type: NEC/CEC
• Area Classification: Ordinary/non-hazardous locations

Product Identification

• UPC: 782274128672
• Dimensions: 5.31 in H x 2.69 in W x 2.69 in D (product)
• Weight: 1.875 lb (manufacturer listed)

FAQ

Does the LCC6 need holes drilled in the tray?
No. Crouse-Hinds designed the LCC series to install without drilling or welding.

Can I put the LCC6 on an inside flange?
The LCC6 is the outside rail version. For inside flanges, Crouse-Hinds makes the LCCF6, and the LCCF line is meant for inside flanges only.

What pipe will the LCC6 clamp?
Use it on 2 in rigid steel, rigid aluminum, IMC, or EMT.

Does the LCC6 bond my conduit to the tray?
Yes. The LCC6 bonds exit conduit to the cable tray and is certified to UL 467 for grounding and bonding.

Do I have to take the clamp apart to install it?
No. The swivel hook moves out of the way of the conduit, so the LCC6 goes on assembled.
