Product Description:
The Square D LEL36600LS is a Molded Case Circuit Breaker from the Micrologic family. It features 3 poles, 600V voltage, and a 600 amp rating with an AIC rating of 65kA@480V. This breaker uses a Feed-Thru connection and includes Solid State protection for reliable performance.
Key Features:
✔ Part Number: LEL36600LS
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Micrologic
✔ Type: LEL
✔ Voltage: 600
✔ Amperage: 600
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 65kA@480V
✔ Connection: Feed-Thru
✔ Functions: LS - Long-Time and Short-Time
✔ Protection: Solid State
✔ Dimensions: Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 39
