Cutler Hammer MDL3800 Circuit Breaker | Series C MDL 600V 800A
Cutler Hammer MDL3800 Circuit Breaker | Series C MDL 600V 800A
Price:
Sale
Sold out
Regular price
$3,333.84 USD
Regular price
$18,289.76 USD
Sale price
$3,333.84 USD
Unit price
per
Shipping calculated at checkout.
Stock:
21 in stock
Couldn't load pickup availability
Product Description:
The Cutler Hammer MDL3800 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 600V, 800A rating and a 50kA@480V AIC rating. This breaker includes Thermal Magnetic protection and uses a Feed-Thru connection.
Key Features:
✔ Part Number: MDL3800
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: MDL
✔ Voltage: 600V
✔ Amperage: 800A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 50kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 800A/M
✔ MCM Size: Min. Wire Size 400 MCM, Max. Wire Size 3 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 782114586006
✔ GTIN: 00782114586006
✔ Country of Origin: United States
The Cutler Hammer MDL3800 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 600V, 800A rating and a 50kA@480V AIC rating. This breaker includes Thermal Magnetic protection and uses a Feed-Thru connection.
