Square D MGL26800 Circuit Breaker | 600V 800A 2P 35kA@480V Lug In/Lug Out Powerpact MGL

Product Description:
The Square D MGL26800 is a Powerpact family molded case circuit breaker designed for reliable circuit protection. It is a 2-pole, 800 amp breaker rated for 600 volts with a 35kA interrupting capacity at 480V. This unit features solid state protection and utilizes a lug in/lug out connection for straightforward installation.

Key Features:
✔ Part Number: MGL26800
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: MGL
✔ Voltage: 600
✔ Amperage: 800
✔ Poles: 2
✔ AIC rating: 35kA@480V
✔ Connection: Lug In/Lug Out
✔ Protection: Solid State
✔ Frame Size: 800A/M
✔ Certification: BS, CCC, CEI, CSA Certified, Federal Specification W-C-375B/GEN, IEC, NEMA, NMX, UL Listed, UNE, UTE, VDE
✔ UPC: 785901507604
✔ GTIN: 00785901507628
