Square D MGP36800 Circuit Breaker | 600V 800A 3P 35kA@480V Bolt-On Powerpact

Product Description:
The Square D MGP36800 is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 800A rating and a 35kA@480V AIC rating. This bolt-on circuit breaker includes solid-state protection and is suitable for industrial applications.

Key Features:
✔ Part Number: MGP36800
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: MGP
✔ Voltage: 600
✔ Amperage: 800
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug, Terminal Nut
✔ Frame Size: M
✔ Wire Size: Min. (3) 3/0 AWG (Cu/Al), Max. (3) 500 kcmil (Cu/Al)
✔ Protection: Solid State
✔ UPC: 785901502494
✔ GTIN: 00785901502494
✔ Country of Origin: Mexico
✔ Dimensions: 20 in x 3.09 in x 4.44 in
✔ Weight: 12.84
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, IEC
