Product Description:
The Square D MXF36800 is a Molded Case Circuit Breaker from the Micrologic family. It features a 3-pole design with a 600V, 800A rating and a 65kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Solid State protection. Lugs are not included with this product.
Key Features:
✔ Part Number: MXF36800
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Micrologic
✔ Type: MXF
✔ Voltage: 600V
✔ Amperage: 800A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: Bolt-On
✔ Functions: LSI (Long-Time, Short-Time, Instantaneous)
✔ Protection: Solid State
✔ Dimensions: 8.05" D x 8.27" W x 12.86" H (204.47mm x 210.06mm x 326.64mm)
✔ Weight: 50 lbs
