Eaton PDG23G0070TFFL Circuit Breaker | 600V 70A 3P 35kA@480V Bolt-On Power Defense

Product Description:
The Eaton PDG23G0070TFFL is a Molded Case Circuit Breaker from the Power Defense family. It features a 3-pole design with a 600V, 70A rating and 35kA@480V AIC rating. This thermal magnetic protection breaker uses a bolt-on connection and is ideal for industrial applications. It meets multiple industry standards including UL 489 and CSA.

Key Features:
✔ Part Number: PDG23G0070TFFL
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Power Defense
✔ Type: PDG
✔ Voltage: 600
✔ Amperage: 70
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Standard Line and Load Side Lug
✔ Frame Size: 225A/Frame 2
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 786679911723
✔ GTIN: 00786679911723
✔ Country of Origin: Dominican Republic
✔ Dimensions: 4.11 in x 6 in
✔ Weight: 4.26 lb
✔ Standards: CCC, CSA, IEC 60947-2, UL 489
✔ Certification: CCC, CSA, IEC 60947-2, RoHS, UL 489
