Eaton PDG23G0100TFFL Molded Case Circuit Breaker | 600V 100A 3P 35kA@480V Bolt-On Power Defense Series

Product Description:
The Eaton PDG23G0100TFFL is a Molded Case Circuit Breaker from the Power Defense Series. It features a 3-pole design with a 600V, 100A rating and a 35kA@480V AIC rating. This breaker uses a Bolt-On connection and offers Thermal Magnetic protection for reliable performance. It is designed for industrial and commercial electrical applications.

Key Features:
✔ Part Number: PDG23G0100TFFL
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Power Defense Series
✔ Type: PDG
✔ Voltage: 600
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Standard Line and Load Side Lug
✔ Frame Size: 225A/Frame 2
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 786679912126
✔ GTIN: 00786679912126
✔ Country of Origin: Dominican Republic
✔ Dimensions: 104.6 mm x 152.4 mm
✔ Weight: 4.26 lb
✔ Standards: UL 489
✔ Certification: CCC, CSA, IEC 60947-2, RoHS, UL 489
