Eaton PDG23M0015MSAJ Circuit Breaker | 600V 15A 65kA@480V Thermal Magnetic Power Defense Series

Product Description:
The Eaton PDG23M0015MSAJ is a Molded Case Circuit Breaker from the Power Defense Series. It operates at 600V with a 15 amp rating and 65kA@480V AIC rating. This breaker features thermal magnetic protection and standard line/load side lug connections. It meets multiple certifications including UL, CSA, and RoHS.

Key Features:
✔ Part Number: PDG23M0015MSAJ
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Power Defense Series
✔ Type: PDG
✔ Voltage: 600
✔ Amperage: 15
✔ AIC rating: 65kA@480V
✔ Terminal Connection: Standard Line and Load Side Lug
✔ Protection: Thermal Magnetic
✔ Weight: 4.9
✔ Certification: CCC, CSA, IEC 60947-2, RoHS, UL 499
