Eaton PDG23M0020TFFL Circuit Breaker | 600V 20A 3P 65kA@480V Bolt-On Power Defense Series

Product Description:
The Eaton PDG23M0020TFFL is a Molded Case Circuit Breaker from the Power Defense Series. It features a 3-pole design with a 600V voltage rating and 20 amp capacity, offering reliable protection with a 65kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection for enhanced safety.

Key Features:
✔ Part Number: PDG23M0020TFFL
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Power Defense Series
✔ Type: PDG
✔ Voltage: 600
✔ Amperage: 20
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 65kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Standard Line and Load Side Lug
✔ Protection: Thermal Magnetic
✔ Trip Type: T-M (Fxd-Fxd) TU
✔ UPC: 786679859384
✔ GTIN: 00786679859384
✔ Country of Origin: Dominican Republic
✔ Dimensions: Length 3.38in, Height 6in, Width 4.13in
✔ Weight: 4.75 lb
✔ Certification: CCC, CSA, IEC 60947-2, RoHS, UL 489
