Eaton PDG23P0100B2NJ Circuit Breaker 600V 100A 3P 100kA@480V Feed-Thru Power Defense Series

Product Description:
The Eaton PDG23P0100B2NJ is a Molded Case Circuit Breaker from the Power Defense Series. It is a 3-pole, 100 amp breaker rated for 600 volts with a 100kA interrupting capacity at 480V. This model features thermal magnetic protection and a feed-thru connection design.

Key Features:
✔ Part Number: PDG23P0100B2NJ
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Power Defense Series
✔ Type: PDG
✔ Voltage: 600
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 100kA@480V
✔ Connection: Feed-Thru
✔ Functions: LSI - Long-Time, Short-Time and Instantaneous
✔ Terminal Connection: Standard Line and Load Side Lug
✔ Protection: Thermal Magnetic
✔ UPC: 786679240380
✔ GTIN: 00786679000000
✔ Country of Origin: Dominican Republic
✔ Dimensions: 152.4 mm x 88.9 mm x 104.6 mm (Height x Length x Width)
✔ Weight: 4.0124084
✔ Certification: UL 489 CCC Marked IEC 60947-2 CSA
