Square D PJA36080CU44A Circuit Breaker | 600V 800A 3P 65kA@480V I-Line Plug-In Powerpact

Product Description:
The Square D PJA36080CU44A is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole breaker rated for 600 Volts and 800 amps, with an interrupting capacity of 65kA at 480V. This unit features I-Line Style Plug-In connections and solid-state protection for reliable performance.

Key Features:
✔ Part Number: PJA36080CU44A
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: PJA
✔ Voltage: 600
✔ Amperage: 800
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
✔ Protection: Solid State
✔ UPC: 785901497141
✔ GTIN: 00785901497141
✔ Country of Origin: United States
✔ Dimensions: Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
✔ Weight: 17.24
