Square D PJA36100U31A Circuit Breaker | 600V 1000A 3P 65kA@480V I-Line Plug-In Powerpact

Product Description:
The Square D PJA36100U31A is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole, 600 Volt, 1000 amp rated breaker with an AIC rating of 65kA@480V. This circuit breaker features a plug-in I-Line connection and solid state protection with MicroLogic 3.0 trip technology.

Key Features:
✔ Part Number: PJA36100U31A
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: PJA
✔ Voltage: 600
✔ Amperage: 1000
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Solid State
✔ Trip Type: MicroLogic 3.0
✔ UPC: 785901044666
✔ GTIN: 00785901044666
✔ Country of Origin: United States
✔ Dimensions: Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 16.16 in (410.46 mm)
✔ Weight: 14.52 lb
✔ Certification: IEC-UL LISTED-CSA
✔ Wire Size: 4 x AWG 3/0...500 kcmil aluminium/copper
