Schneider Electric PJL26000S10 Molded Case Circuit Breaker | 600V 1000A 2P 65kA@480V Feed-Thru Powerpact PJL

Product Description:
The Schneider Electric PJL26000S10 is a Molded Case Circuit Breaker from the Powerpact family. This 2-pole breaker is rated for 1000 amps and 600 volts, with an interrupting capacity of 65kA at 480V. It features a feed-thru connection and provides non-automatic protection.

Key Features:
✔ Part Number: PJL26000S10
✔ Manufacturer: Square D||Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: PJL
✔ Voltage: 600
✔ Amperage: 1000
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 65kA@480V
✔ Connection: Feed-Thru
✔ Functions: NA - No Overcurrent Protection
✔ Frame Size: P Frame
✔ Protection: Non-Automatic
✔ UPC: 762179036296
✔ Dimensions: Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 16.16 in (410.46 mm)
✔ Weight: 37
