Product Description:
The Square D PLA34060U31A is a 3-pole molded case circuit breaker with a 600A rating and 480V voltage capacity. It features a 100kA@480V AIC rating and uses an I-Line Style Plug-In connection. The breaker includes solid-state protection and supports 3 x AWG 3/0...500 kcmil aluminum/copper wire sizes. It operates within a temperature range of 28-158°F (-2-70°C).
Key Features:
✔ Part Number: PLA34060U31A
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Voltage: 480V
✔ Amperage: 600A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 100kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Temp Rating: 28-158°F (-2-70°C)
✔ Wire Size: 3 x AWG 3/0...500 kcmil aluminum/copper
✔ Dimensions: 12.86 x 3.09 x 4.44 in (326.64 x 78.49 x 112.78 mm)
✔ Weight: 32 lbs
