Square D PLA34080U31A Circuit Breaker | Powerpact PLA 480V 800A

Product Description:
The Square D PLA34080U31A is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 480V, 800A rating and a 100kA@480V AIC rating. This breaker uses an I-Line Style Plug-In connection and includes solid-state protection. It is suitable for wire sizes ranging from 3 x AWG 3/0 to 500 kcmil aluminum/copper.

Key Features:
✔ Part Number: PLA34080U31A
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: PLA
✔ Voltage: 480V
✔ Amperage: 800A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 100kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: P Frame
✔ Temp Rating: 28-158 °F (-2-70 °C)
✔ Wire Size: 3 x AWG 3/0...500 kcmil aluminum/copper
✔ UPC: 060648628603
✔ GTIN: 03606486286036
✔ Dimensions: 12.86 x 3.09 x 4.44 in (326.64 x 78.49 x 112.78 mm)
✔ Weight: 48.5 lbs
