Square D PLA34120U33A Molded Case Circuit Breaker | 480V 1200A 3P 100kA@480V I-Line Style Plug-In Powerpact

Product Description:
The Square D PLA34120U33A is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole breaker rated for 1200 amps at 480 volts with a 100kA interrupting capacity. This unit features a plug-in I-Line connection and solid-state protection with LSI functions.

Key Features:
✔ Part Number: PLA34120U33A
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: PLA
✔ Voltage: 480
✔ Amperage: 1200
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 100kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LSI - Long-Time, Short-Time and Instantaneous
✔ Frame Size: P Frame
✔ Protection: Solid State
✔ UPC: 762179036777
✔ Dimensions: Height 16.16 in (410.46 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 14.52
✔ Wire Size: 4 x AWG 3/0...500 kcmil aluminum/copper
