Product Description:
The Square D QDA222004 is a Molded Case Circuit Breaker from the I-Line family. It features a 2-pole design with a 240V, 200A rating and a 25kA@240V AIC rating. This breaker uses a Plug In Panelboard connection and includes Thermal Magnetic protection. It is UL Listed and CSA Certified for safety compliance.
Key Features:
✔ Part Number: QDA222004
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: I-Line
✔ Type: QDA
✔ Voltage: 240V
✔ Amperage: 200A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 25kA@240V
✔ Connection: Plug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 250A/QD
✔ MCM Size: Min. Wire Size 4 AWG, Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Temp Rating: 104-158 °F (40-70 °C)
✔ Certification: UL Listed, CSA Certified, CE Marked,
