Square D QGL22150 Circuit Breaker | 240V 150A 2P 65kA@240V Feed-Thru Powerpact

Product Description:
The Square D QGL22150 is a Molded Case Circuit Breaker from the Powerpact family. It is a 2-pole, 240 Volt, 150 amp breaker with a 65kA@240V AIC rating. This circuit breaker uses a Feed-Thru connection and provides Thermal Magnetic protection.

Key Features:
✔ Part Number: QGL22150
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QGL
✔ Voltage: 240
✔ Amperage: 150
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 65kA@240V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: Q
✔ Protection: Thermal Magnetic
✔ UPC: 785901524045
✔ GTIN: 00785901524045
✔ Country of Origin: Mexico
✔ Dimensions: Height 6.47 in (164.34 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.54
✔ Standards: UL, CSA, NEMA, NOM
✔ Certification: UL, IEC, CSA
✔ Wire Size: 4 AWG to 300 kcmil Al/Cu
