Square D QO315GFI Circuit Breaker | 120/240V 15A 3P 10kA@240V Plug-In QO Series

Product Description:
The Square D QO315GFI is a molded case circuit breaker designed for reliable electrical protection. It is a 3-pole, 15-amp breaker rated for 120/240 volts with a 10kA interrupting capacity. This GFCI model offers thermal magnetic protection and is compatible with QO load centers and NQ panelboards. It meets UL and CSA standards for safety and performance.

Key Features:
✔ Part Number: QO315GFI
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QO Series
✔ Type: QO
✔ Voltage: 120/240
✔ Amperage: 15
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 10kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Pressure Plate
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 8 AWG
✔ Breaker Type: Ground Fault Circuit Interrupter (Class A - 5mA)
✔ Protection: Thermal Magnetic
✔ UPC: 785901652311
✔ GTIN: 00785901652311
✔ Country of Origin: Mexico
✔ Dimensions: 2.24 in x 4.12 in x 4.13 in
✔ Weight: 1
✔ Panel Type: QO Load Centers and NQ Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
✔ Wire Size: AWG 14 to AWG 8 Copper, AWG 12 to AWG 8 Aluminum
