Square D QO330GFI Circuit Breaker | 120/240V 30A 3P 10kA@240V Plug-In QO Series

Product Description:
The Square D QO330GFI is a 3-pole molded case circuit breaker designed for 120/240 Volt systems. It provides reliable thermal magnetic protection and is rated for 30 amps with a 10kA interrupting capacity at 240V. This plug-in breaker is compatible with QO load centers and NQ panelboards, ensuring safe and efficient circuit management.

Key Features:
✔ Part Number: QO330GFI
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QO Series
✔ Type: QO
✔ Voltage: 120/240
✔ Amperage: 30
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 10kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Pressure Plate
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 8 AWG
✔ Breaker Type: Ground Fault Circuit Interrupter (Class A - 5mA)
✔ Protection: Thermal Magnetic
✔ UPC: 785901218975
✔ GTIN: 00785901218975
✔ Country of Origin: Mexico
✔ Dimensions: 2.24 in x 4.12 in x 4.13 in
✔ Weight: 1
✔ Panel Type: QO Load Centers and NQ Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
✔ Wire Size: AWG 14, AWG 8 Copper, AWG 12, AWG 8 Aluminium
