Square D QO340VH Circuit Breaker | 240V 40A 3P 22kA@240V Plug-In QO Series

Product Description:
The Square D QO340VH is a 3-pole molded case circuit breaker rated for 40 amps at 240 volts. It features a plug-in connection and provides thermal magnetic protection for reliable circuit interruption. This high interrupting capacity breaker is designed for use in QO load centers and NQ panelboards.

Key Features:
✔ Part Number: QO340VH
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QO Series
✔ Type: QO
✔ Voltage: 240
✔ Amperage: 40
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 22kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 4 AWG Max. Wire Size 2 AWG
✔ Breaker Type: High Interrupting Capacity
✔ Protection: Thermal Magnetic
✔ UPC: 785901060208
✔ GTIN: 00785901060208
✔ Country of Origin: Mexico
✔ Dimensions: 2.24 in x 3.12 in x 3.11 in
✔ Weight: 1
✔ Panel Type: QO Load Centers and NQ Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
