Square D QO390VH Circuit Breaker 240V 90A 3P 22kA@240V Plug-In QO Series

Product Description:
The Square D QO390VH is a Molded Case Circuit Breaker from the QO Series family. It is a 3-pole, 240 Volt, 90 amp breaker with a 22kA@240V AIC rating and Plug-In connection. This model provides reliable Thermal Magnetic protection for electrical systems. It is designed for use in QO Load Centers and NQ Panelboards.

Key Features:
✔ Part Number: QO390VH
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QO Series
✔ Type: QO
✔ Voltage: 240
✔ Amperage: 90
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 22kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 4 AWG Max. Wire Size 2 AWG
✔ Breaker Type: High Interrupting Capacity
✔ Protection: Thermal Magnetic
✔ UPC: 785901120612
✔ GTIN: 00785901120612
✔ Country of Origin: Mexico
✔ Dimensions: 2.24 in x 3.5 in x 3.5 in
✔ Weight: 494.42
✔ Panel Type: QO Load Centers and NQ Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
