Product Description:
The Square D QOB3701021 is a molded case circuit breaker designed for reliable electrical protection. It is a 3-pole, 70 amp breaker rated for 240 volts with a 10kA interrupting capacity. This thermal magnetic circuit breaker features a bolt-on connection for secure installation. It is suitable for use in Square D NQOD panelboards and meets UL and CSA standards.
Key Features:
✔ Part Number: QOB3701021
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOB Series
✔ Type: QOB
✔ Voltage: 240
✔ Amperage: 70
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 4 AWG Max. Wire Size 2 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 785901031031
✔ GTIN: 00785901031031
✔ Country of Origin: Mexico
✔ Dimensions: 3 in x 3.12 in x 3.11 in
✔ Weight: 1.34
✔ Panel Type: Square D NQOD Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
