Hammond Power Solutions SK3A0750KK9K 3-Phase Transformer 750kVA 480D-480Y/277V
Hammond Power Solutions SK3A0750KK9K 3-Phase Transformer 750kVA 480D-480Y/277V
Price:
Sale
Sold out
Regular price
$83,690.21 USD
Regular price
$122,900.00 USD
Sale price
$83,690.21 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
⚠️ Special Order Policy – Hammond Products
Hammond transformers are built to order and processed immediately after purchase. All Hammond items are Non-Cancellable and Non-Returnable once the order is placed. Please confirm specifications carefully before checkout.
Product Description:
This three-phase transformer is designed for general duty industrial power distribution applications. It features a 750 kVA capacity with a 480V delta primary and 480Y/277V wye secondary configuration. The unit is housed in a Type 3R/IP24 enclosure and complies with major efficiency and seismic standards. Typical applications include industrial facilities, commercial buildings, and power distribution systems.
Key Features:
✔ Part Number: SK3A0750KK9K
✔ Manufacturer: Hammond Power Solutions
✔ Category: Transformer
✔ Phase: 3
✔ Duty: General Duty
✔ Frequency: 60Hz
✔ Primary Voltage: 480D
✔ Primary Connection: Delta
✔ Secondary Voltage: 480Y/277
✔ Secondary Connection: Wye-N
✔ Temperature Rise: 150°C
✔ Insulation Class: 220°C
✔ Efficiency Regulation: DOE 2016 (US), NRCAN 2019 (Canada), NMX 2021 (Mexico)
✔ Seismic Compliance: IBC 2018 (Sds=2.0, z/h=0, lp=1.5)
✔ Sound Level: 64 dBA (NEMA ST-20)
✔ Impedance (Std): 4% - 7.5%
✔ Enclosure Type: Type 3R / IP24
✔ Enclosure Finish: ANSI 61 Grey, UL50
✔ Enclosure Dimensions: 64in/1626mm(H), 49in/1245mm(W), 39in/991mm(D)
✔ Electrostatic Shield: Single
✔ Standard kVA: 750
✔ Vector Configuration: Dyn1 (-30°)
✔ Weight: 4220
✔ Certification: CSA, UL
Resources:
✔ Engineering Drawing (PDF)
✔ Brochure
✔ Hammond Product Application Videos
✔ Frequently Asked Questions
✔ Troubleshooting Guide
✔ Enclosure CAD Drawing (PDF)
