Cutler Hammer XTCE015B10A Contactor | 3P 3PH 600V 15A 120V Coil XT Series

Product Description:
The Cutler Hammer XTCE015B10A XT Series Contactor is a 600V 3-phase 15A 3-pole starter with a 120V coil. It offers horsepower ratings of 5 hp at 208V/240V and 10 hp at 480V. This IEC non-reversing contactor includes one normally open auxiliary contact and is compatible with PDG Frame 4.

Key Features:
✔ Part Number: XTCE015B10A
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: XT Series
✔ Type: XTCE015B
✔ Voltage: 600
✔ Amperage: 15
✔ Phase: 3
✔ Poles: 3
✔ Horse Power: HP @ 3 Phase - 208V 5 hp HP @ 3 Phase - 240V 5 hp HP @ 3 Phase - 480V 10 hp
✔ Configuration: Non-Reversing
✔ Aux Contacts: 1 NO
✔ Coil Voltage Maximum: 120
✔ Full Load Amps: Full Load Amps-Inductive 15A Full Load Amps-Resistive 22A
✔ Coil Voltage Minimum: 120
✔ Compatible Frames: PDG, PDG Frame 4
✔ Frequency: 50 Hz
✔ UPC: 015082900551
✔ GTIN: 04015080000000
✔ Country of Origin: Romania
✔ Dimensions: 1.77 in x 1.77 in
✔ Weight: 1 lb
✔ Certification: CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
