Cutler Hammer XTCE032C10C Contactor | 3P 3PH 600V 32A 480V coil XT Series

Product Description:
The Cutler Hammer XTCE032C10C XT Series Contactor is a 600V 3-phase 32A 3-pole starter with a 480V coil. It offers horsepower ratings of 10 hp at 208V/240V and 20 hp at 480V. This IEC non-reversing contactor includes a 412 VAC coil and is designed for reliable motor control applications.

Key Features:
✔ Part Number: XTCE032C10C
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: XT Series
✔ Type: XTCE032C
✔ Voltage: 600
✔ Amperage: 32
✔ Phase: 3
✔ Poles: 3
✔ Horse Power: HP @ 3 Phase - 208V 10 hp HP @ 3 Phase - 240V 10 hp HP @ 3 Phase - 480V 20 hp
✔ Configuration: Non-Reversing
✔ Aux Contacts: 1 NO
✔ Coil Voltage Maximum: 480
✔ Full Load Amps: Full Load Amps-Inductive 32A Full Load Amps-Resistive 45A
✔ Coil Voltage Minimum: 480
✔ Frequency: 50 Hz
✔ UPC: 401508277263
✔ Country of Origin: Romania
✔ Dimensions: 1.77 in x 1.77 in
✔ Weight: 1 lb
✔ Certification: CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
