Cutler Hammer XTCE095F00A Contactor | 3P 3PH 600V 95A 120V Coil XT Series

Product Description:
The Cutler Hammer XTCE095F00A XT Series Contactor is a 600V 3-phase 95A 3-pole starter with a 120V coil. It offers horsepower ratings of 25 hp at 208V, 40 hp at 240V, and 75 hp at 480V. This IEC non-reversing contactor is designed for motor control applications.

Key Features:
✔ Part Number: XTCE095F00A
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: XT Series
✔ Type: XTCE095F
✔ Voltage: 600
✔ Amperage: 95
✔ Phase: 3
✔ Poles: 3
✔ Horse Power: HP @ 3 Phase - 208V 25 hp HP @ 3 Phase - 240V 40 hp HP @ 3 Phase - 480V 75 hp
✔ Configuration: Non-Reversing
✔ Aux Contacts: 0 NO + 0 NC
✔ Coil Voltage Maximum: 120
✔ Full Load Amps: Full Load Amps-Inductive 95A Full Load Amps-Resistive 130A
✔ Coil Voltage Minimum: 120
✔ Frequency: 50 Hz
✔ UPC: 01508239477
✔ GTIN: 04015082394776
✔ Country of Origin: Romania
✔ Dimensions: 3.54 in x 3.54 in
✔ Weight: 1 lb
✔ Certification: CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
