Siemens B235H Circuit Breaker | 120/240V 35A 2P 22kA@240V Bolt-on BL Series
Siemens B235H Circuit Breaker | 120/240V 35A 2P 22kA@240V Bolt-on BL Series
Price:
Sale
Sold out
Regular price
$67.50 USD
Regular price
$401.00 USD
Sale price
$67.50 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Low stock: 1 left
Couldn't load pickup availability
Product Description:
The Siemens B235H is a Molded Case Circuit Breaker from the BL Series family. It is a 2-pole, 35 amp breaker designed for 120/240V systems with an interrupting capacity of 22kA at 240V. This model features thermal magnetic protection and a bolt-on connection for secure installation. It is suitable for use in Siemens P1 panelboards and complies with CSA, HACR, and UL standards.
Key Features:
✔ Part Number: B235H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLH
✔ Voltage: 120/240
✔ Amperage: 35
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BLH
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 783643089082
✔ GTIN: 00783643089082
✔ Country of Origin: Mexico
✔ Dimensions: 3 in x 2 in x 2 in
✔ Weight: 0.73
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: CSA, HACR, UL
✔ Certification: CSA, HACR, UL
The Siemens B235H is a Molded Case Circuit Breaker from the BL Series family. It is a 2-pole, 35 amp breaker designed for 120/240V systems with an interrupting capacity of 22kA at 240V. This model features thermal magnetic protection and a bolt-on connection for secure installation. It is suitable for use in Siemens P1 panelboards and complies with CSA, HACR, and UL standards.
Key Features:
✔ Part Number: B235H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLH
✔ Voltage: 120/240
✔ Amperage: 35
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BLH
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 783643089082
✔ GTIN: 00783643089082
✔ Country of Origin: Mexico
✔ Dimensions: 3 in x 2 in x 2 in
✔ Weight: 0.73
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: CSA, HACR, UL
✔ Certification: CSA, HACR, UL
