Siemens B245H00S01 Molded Case Circuit Breaker | 120/240V 45A 2P 22kA@240V BL Series

Product Description:
The Siemens B245H00S01 is a molded case circuit breaker designed for reliable electrical protection. It features a 2-pole configuration with a 120/240V rating and 45A amperage capacity. This breaker includes thermal magnetic protection and a bolt-on connection for secure installation. It is compatible with Siemens P1 panelboards and meets industry standards including UL, CSA, and HACR.

Key Features:
✔ Part Number: B245H00S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLH
✔ Voltage: 120/240
✔ Amperage: 45
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BLH
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643524750
✔ GTIN: 00783643524750
✔ Country of Origin: United States
✔ Dimensions: 3 in x 2 in x 2 in
✔ Weight: 0.71
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: CSA, HACR, UL
✔ Certification: CSA, HACR, UL
