Siemens B335HH00S01 Molded Case Circuit Breaker | 240V 35A 3P 65kA@240V BL Series
Siemens B335HH00S01 Molded Case Circuit Breaker | 240V 35A 3P 65kA@240V BL Series
Price:
Sale
Sold out
Regular price
$446.15 USD
Regular price
$1,506.00 USD
Sale price
$446.15 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Siemens B335HH00S01 is a molded case circuit breaker designed for reliable electrical protection in industrial and commercial settings. It features a 3-pole configuration with a 240V voltage rating and 35A amperage capacity. This circuit breaker includes thermal magnetic protection and a bolt-on connection for secure installation. It is also equipped with a 120V shunt trip function for enhanced control.
Key Features:
✔ Part Number: B335HH00S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: HBL
✔ Voltage: 240
✔ Amperage: 35
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BL
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643529632
✔ GTIN: 00783643529632
✔ Country of Origin: Mexico
✔ Dimensions: 3 in x 3 in x 3 in
✔ Weight: 2.21
✔ Panel Type: P1 Panelboards
✔ Standards: UL 489
✔ Certification: UL 489
