Schneider Electric BDA160305 Circuit Breaker | Powerpact BDA 600V 30A

Product Description:
The Schneider Electric BDA160305 is a Molded Case Circuit Breaker from the Powerpact family. It features a 1-pole design with a 600V, 30A rating and a 25kA@240V AIC rating. This breaker uses an I-Line Style Plug-In connection and includes Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: BDA160305
✔ Manufacturer: Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600V
✔ Amperage: 30A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 25kA@240V
✔ Connection: I-Line Style Plug-In
✔ Protection: Thermal Magnetic
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: D
✔ Wire Size: 14 AWG to 2/0 AWG (Cu/Al)
✔ Standards: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ Certification: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ UPC: 060648115133
✔ GTIN: 03606481151339
✔ Country of Origin: Mexico
