Schneider Electric BDA160905 Circuit Breaker | 600V 90A 1P 25kA@240V I-Line Style Plug-In Powerpact

Product Description:
The Schneider Electric BDA160905 is a Molded Case Circuit Breaker from the Powerpact family. It features 1 pole, 600V voltage, and 90A amperage with a 25kA@240V AIC rating. This breaker uses an I-Line Style Plug-In connection and offers Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: BDA160905
✔ Manufacturer: Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600
✔ Amperage: 90
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 25kA@240V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: B Frame
✔ Protection: Thermal Magnetic
✔ UPC: 060648115141
✔ GTIN: 03606481151414
✔ Dimensions: Height 5.39 in (137 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
