Schneider Electric BDA161005 Circuit Breaker | 600V 100A 1P 25kA@240V I-Line Style Plug-In Powerpact

Product Description:
The Schneider Electric BDA161005 is a Molded Case Circuit Breaker from the Powerpact family. It features a 1 pole design with a 600 Volt rating and 100 amp capacity, suitable for various electrical applications. This breaker offers Thermal Magnetic protection and has an AIC rating of 25kA@240V. It uses an I-Line Style Plug-In connection for easy installation.

Key Features:
✔ Part Number: BDA161005
✔ Manufacturer: Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600
✔ Amperage: 100
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 25kA@240V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: B Frame
✔ Protection: Thermal Magnetic
✔ UPC: 060648115142
✔ GTIN: 03606481151421
✔ Dimensions: Height 5.39 in (137 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
