Square D BDA260304 Circuit Breaker | 600V 30A 2P 18kA@480V I-Line Plug-In Powerpact

Product Description:
The Square D BDA260304 is a Molded Case Circuit Breaker from the Powerpact family. It is a 2-pole, 30 amp breaker rated for 600 Volts with an 18kA@480V AIC rating. This thermal magnetic breaker features an I-Line Style Plug-In connection for easy installation.

Key Features:
✔ Part Number: BDA260304
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600
✔ Amperage: 30
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: D
✔ MCM Size: Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ Phase Connection: BC
✔ UPC: 060648115212
✔ GTIN: 03606481152121
✔ Country of Origin: Mexico
✔ Dimensions: 2.12 in x 5.39 in
✔ Weight: 1.46
✔ Standards: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ Certification: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
