Schneider Electric BDA260804 Circuit Breaker | 600V 80A 2P 18kA@480V I-Line Style Plug-In Powerpact
Schneider Electric BDA260804 Circuit Breaker | 600V 80A 2P 18kA@480V I-Line Style Plug-In Powerpact
Price:
Sale
Sold out
Regular price
$956.92 USD
Regular price
$1,468.50 USD
Sale price
$956.92 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Low stock: 3 left
Couldn't load pickup availability
Product Description:
The Schneider Electric BDA260804 is a Molded Case Circuit Breaker from the Powerpact family. It features 2 poles, 600V voltage, and an 80A amperage rating with an AIC rating of 18kA@480V. This breaker uses an I-Line Style Plug-In connection and offers Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: BDA260804
✔ Manufacturer: Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: D
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
✔ Protection: Thermal Magnetic
✔ Phase Connection: BC
✔ UPC: 060648115229
✔ GTIN: 00785901035671
✔ Country of Origin: Mexico
✔ Dimensions: 2.12 in x 5.39 in
✔ Weight: 1.31
✔ Standards: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ Certification: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
The Schneider Electric BDA260804 is a Molded Case Circuit Breaker from the Powerpact family. It features 2 poles, 600V voltage, and an 80A amperage rating with an AIC rating of 18kA@480V. This breaker uses an I-Line Style Plug-In connection and offers Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: BDA260804
✔ Manufacturer: Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: D
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
✔ Protection: Thermal Magnetic
✔ Phase Connection: BC
✔ UPC: 060648115229
✔ GTIN: 00785901035671
✔ Country of Origin: Mexico
✔ Dimensions: 2.12 in x 5.39 in
✔ Weight: 1.31
✔ Standards: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
✔ Certification: UL 489, CSA C22.2 No 5, IEC, CCC, EAC, NOM, CE, NEMA AB1, NMX J-266
