Square D BDA36035 Circuit Breaker | Powerpact BDA 600V 35A
Square D BDA36035 Circuit Breaker | Powerpact BDA 600V 35A
Price:
Sale
Sold out
Regular price
$655.00 USD
Regular price
$1,012.00 USD
Sale price
$655.00 USD
Unit price
per
Shipping calculated at checkout.
Stock:
46 in stock
Couldn't load pickup availability
Product Description:
The Square D BDA36035 is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 35A rating and an 18kA@480V AIC rating. This breaker uses I-Line connections and includes Thermal Magnetic protection for reliable performance. Key Features:
✔ Part Number: BDA36035
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600V
✔ Amperage: 35A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 18kA@480V
✔ Connection: I-Line
✔ Protection: Thermal Magnetic
✔ Frame Size: 125A/BD
✔ Wire Size: 14 AWG to 2 AWG
✔ Certification: CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
✔ UPC: 785901051244
✔ GTIN: 00785901051244
The Square D BDA36035 is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 35A rating and an 18kA@480V AIC rating. This breaker uses I-Line connections and includes Thermal Magnetic protection for reliable performance. Key Features:
✔ Part Number: BDA36035
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDA
✔ Voltage: 600V
✔ Amperage: 35A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 18kA@480V
✔ Connection: I-Line
✔ Protection: Thermal Magnetic
✔ Frame Size: 125A/BD
✔ Wire Size: 14 AWG to 2 AWG
✔ Certification: CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
✔ UPC: 785901051244
✔ GTIN: 00785901051244
