Siemens BE250H Circuit Breaker | 120/240V 50A 2P 22kA@240V Bolt-On BL Series

Product Description:
The Siemens BE250H is a Molded Case Circuit Breaker from the BL Series family. It is a 2-pole, 50 amp breaker rated for 120/240V systems with an AIC rating of 22kA@240V. This thermal magnetic circuit breaker uses a bolt-on connection for secure installation. It is designed for use in Siemens P1 panelboards and meets multiple industry certifications.

Key Features:
✔ Part Number: BE250H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLEH
✔ Voltage: 120/240
✔ Amperage: 50
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Lug
✔ Frame Size: 60A/BLEH
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Ground Fault Equipment Protection
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
✔ Certification: CSA Certified, HACR Rated, NOM Certified, UL Listed
✔ UPC: 783643274204
✔ GTIN: 00783643274204
✔ Country of Origin: Mexico
✔ Dimensions: 3 in x 6 in x 6 in
✔ Weight: 1.05
