Siemens BF230H Molded Case Circuit Breaker | 120/240V 30A 2P 22kA@240V Bolt-on BL Series

Product Description:
The Siemens BF230H is a Molded Case Circuit Breaker from the BL Series family. It is a 2-pole, 30 amp breaker designed for 120/240 Volt systems with an AIC rating of 22kA@240V. This model features thermal magnetic protection and a bolt-on connection for secure installation. It is suitable for use in Siemens panelboards and meets multiple industry standards.

Key Features:
✔ Part Number: BF230H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLHF
✔ Voltage: 120/240
✔ Amperage: 30
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 60A/BLHF
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Ground Fault Circuit Interrupter (Class A - 5mA)
✔ Protection: Thermal Magnetic
✔ UPC: 783643274068
✔ GTIN: 00783643274068
✔ Country of Origin: Philippines
✔ Dimensions: 4 in x 6 in x 6 in
✔ Weight: 2
✔ Panel Type: Siemens Panelboards
✔ Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
✔ Certification: CSA Certified, HACR Rated, NOM Certified, UL Listed
