Siemens BF240H Circuit Breaker | 240V 40A 2P 22kA@240V Bolt-on BL Series

Product Description:
The Siemens BF240H is a Molded Case Circuit Breaker from the BL Series family. It features 2 poles, 240V voltage, and 40A amperage with a 22kA@240V AIC rating. This breaker uses a bolt-on connection and offers thermal magnetic protection. It is designed for use in Siemens panelboards.

Key Features:
✔ Part Number: BF240H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLHF
✔ Voltage: 240
✔ Amperage: 40
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 60A/BLHF
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Ground Fault Circuit Interrupter (Class A - 5mA)
✔ Protection: Thermal Magnetic
✔ UPC: 783643274068
✔ Country of Origin: Philippines
✔ Panel Type: Siemens Panelboards
✔ Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
