Siemens BQ3B09000S01 Circuit Breaker | 240V 90A 3P 10kA@240V Bolt-on BQ Series

Product Description:
The Siemens BQ3B09000S01 is a 3-pole molded case circuit breaker with a 90 amp rating and 240V voltage. It features thermal magnetic protection and a bolt-on connection for secure installation. This breaker has an AIC rating of 10kA@240V and is part of the BQ Series family. It is designed for use in Siemens panelboards and meets HACR and UL standards.

Key Features:
✔ Part Number: BQ3B09000S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BQ Series
✔ Type: BQ
✔ Voltage: 240
✔ Amperage: 90
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BQ
✔ MCM Size: Min. Wire Size 8 AWG Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643237902
✔ GTIN: 00783643237902
✔ Country of Origin: Mexico
✔ Dimensions: 3.937 x 4.724 x 3.937
✔ Weight: 2
✔ Panel Type: Siemens Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR, UL
✔ Wire Size: 2 AWG (Al), 4 AWG (Cu) Min, 1/0 AWG Max
