Siemens ED41B020 Circuit Breaker | 120V 20A 1P 65kA@120V Lug In Panelboard Sentron Series

Product Description:
The Siemens ED41B020 is a Molded Case Circuit Breaker from the Sentron Series family. It is a 1-pole, 20 amp breaker rated for 120 volts with an AIC rating of 65kA. This circuit breaker features thermal magnetic protection and is designed for use with a lug-in panelboard connection.

Key Features:
✔ Part Number: ED41B020
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: ED
✔ Voltage: 120
✔ Amperage: 20
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 65kA@120V
✔ Connection: Lug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 125A/ED
✔ MCM Size: Min. Wire Size 10 AWG Max. Wire Size 4 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: Any
✔ UPC: 783643209091
✔ GTIN: 00783643209091
✔ Country of Origin: United States
✔ Dimensions: 1 in x 6.34 in
✔ Weight: 3
✔ Panel Type: SB Switchboards, Sentron Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR Rated, UL Listed
