Product Description:
The Schneider Electric EDB14015SA is a Molded Case Circuit Breaker from the EDB Series. It features a 1 pole design with a 277V voltage rating and 15A amperage. This circuit breaker offers Thermal Magnetic protection and has an AIC rating of 18kA@480V. It includes a 120V shunt trip and uses a Bolt-On connection.
Key Features:
✔ Part Number: EDB14015SA
✔ Manufacturer: Schneider Electric||Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 277
✔ Amperage: 15
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ GTIN: 00785901691372
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Panel Type: NF panelboard
✔ Certification: cULus - IEC
✔ Wire Size: AWG 12...AWG 6 aluminum, AWG 14...AWG 6 copper
