Square D EDB24060SA Circuit Breaker | 480V 60A 2P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB24060SA is a Molded Case Circuit Breaker from the EDB Series. It features a 2-pole design with a 480V voltage rating and 60 amp capacity, offering an AIC rating of 18kA@480V. This bolt-on circuit breaker includes thermal magnetic protection and comes complete with a 120V shunt trip. Ideal for industrial and commercial electrical systems.

Key Features:
✔ Part Number: EDB24060SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 480
✔ Amperage: 60
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ UPC: 785901879091
✔ GTIN: 00785901963219
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.44
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
