Schneider Electric EDB24090SA Circuit Breaker | 480V 90A 2P 18kA@480V Bolt-On EDB Series

Product Description:
The Schneider Electric EDB24090SA is a 2-pole molded case circuit breaker with a 480V voltage rating and 90A amperage. It features thermal magnetic protection and an 18kA@480V AIC rating, designed for reliable performance in electrical systems. This bolt-on connection breaker is part of the EDB Series and includes a 120V shunt trip.

Key Features:
✔ Part Number: EDB24090SA
✔ Manufacturer: Schneider Electric||Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 480
✔ Amperage: 90
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ GTIN: 00785901546702
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
